Children with cerebral palsy and hemiparesis following MIRA therapy

Posted on Posted in Case studies, MIRA Research

I M Moldovan1, O Ghircău1, A Podar1, O Rîză1, R A Moldovan2

1Socio-medical services complex ”Maria Beatrice”, Alba-Iulia, ROMANIA, ongmariabeatrice@yahoo.com

2Alba-Iulia Emergency County Hospital

This work has been published in the Journal PALESTRICA OF THE THIRD MILLENNIUM, Civilization and Sport, Vol. 18, no. 1, January-March 2017, 38–41, with the title Virtual occupational therapy in a child with cerebral palsy. Below we present a summary of the study.



Abstract

Adapted Movement-Based Interactive Video Games (MBIVG) and the Microsoft’s Kinect motion sensor constitute a promising new therapy for children with cerebral palsy (CP). We report the evolution of a 7 year old girl with cerebral palsy stage I GMFCS and stage I MACS presenting with left hemiparesis predominant in the lower limb, who played MIRA interactive video games using the Kinect sensor for 14 months, with a frequency of 3 sessions/week and a duration of 30 minutes/session. During this period she also benefited from conventional therapy for CP (kinetotherapy, hydrokinetotherapy and conventional occupational therapy).

Introduction

Play is a central part in a child’s life. With new sensors such as Microsoft Kinect, children can play videogames which resemble the conventional physiotherapy for children with neurological impairments. The fun and innovative way MIRA exergames can be used to motivate children seems to be effective in improving activities required for daily living, such as motor control and balance.

MIRA Rehab has developed clinically-based video exergames (exercises in the form of games) as a tool for rehabilitation therapy, involving exercises that have the potential to improve motor function. The purpose of this case study was to describe the evolution of a young girl with cerebral palsy (CP) who played MIRA interactive videogames for 14 months, whilst also benefiting from conventional therapy for CP.



The case presentation

S.I. is a 7 year old girl, diagnosed with left spastic hemiparesis cerebral palsy, level I according to the Gross Motor Function Classification System1 (GMFCS) and level I according to the Manual Ability Classification System2 (MACS) caused by hypoxic-ischemic injury (lack of oxygen) at birth.

img_9197

Pre-intervention

Since the age of one, S.I. started a physical therapy programme, consisting of kinetotherapy (treatment of disease through movement and exercise), hydrokinetotherapy (treatment through movement and exercise in water), and occupational therapy. During our first visit to S.I., in October 2014, she complained of difficulty in running, jumping, climbing stairs and playing games that require coordinating both hands.

On clinical examination, there was a positive Babinski sign on the left side, which is consistent with patients with a neurological condition, and asymmetric deep tendon reflexes (exaggerated on the left side). In addition to these observations, a moderate spasticity, quantified as 2 on the Modified Ashworth Scale was noticed for the triceps surae (a muscle in the lower leg). An abnormality in purposeful movements in the left hand was recorded, and due to this, she predominantly used her right hand.  More complex movements could be performed with both hands, however with a moderate difficulty with the left hand.

Although S.I. was able to walk independently, she had trouble placing her left heel on the floor to initiate the walking movement (heel strike). She was able to run at a slow speed, and was unable to perform a left single leg jump or maintain balance using solely the left foot.



The intervention

Since October 2014, she benefited from virtual gamified therapy with MIRA. The interactive video-games from the MIRA platform (Move, Follow, Catch) were played for 30 minutes per session, 3 times each week from October 2014 until December 2015.

img_9224

Follow-up results

The table below shows the scores pre and post Mira intervention.

 Score  Initial Score  Final Score  Amendment  Maximum score
ABILHAND-Kids 37 39 4.76% 42
QUEST 95.52 97.76 2.24% 100
Paediatric Balance Scale 49 54 9.25% 56
MIRA 1489 1895 33.31%

Figure 1. Evolution of the total points for the left and the right hand gained in the MIRA testing schedule during 11 sessions of evaluation

For further information on these scales, please click on the following links: ABILHAND-Kids Scale, Quest, and Paediatric Balance Scale.



At the final visit, S.I. showed improved motor skills, and was able to run and climb stairs without assistance. She no longer complained of difficulty in playing games that required coordination of both hands, and did not neglect her left side. Attention and visual-spatial skills were also improved. The spasticity on the triceps surae muscle in the leg decreased from 2+ to 1+ on the Modified Ashworth Scale. Heel strike on her left foot was possible with the use of orthopaedic shoes and hinged ankle foot orthosis (a device used to support the ankle). The independent finger movements of the left hand and jumping on one foot remained impossible, whilst balancing on her left foot was possible for less than 10 seconds.

Both parents and the child considered the MIRA system as “very efficient” in the final satisfaction questionnaire. No adverse effect of the exergaming was reported during 14 months of treatment.

Discussion and conclusion

MIRA games train the gross motor skills of the upper and lower limbs, the body’s balance and coordination, visual-spatial ability and hand-to-eye coordination. The exergames also have the ability to increase the attention of the patient and limit their spatial neglect. The patient’s enhanced capabilities were noted in four assessments completed.   The area with the most progress achieved was in balance and coordination.

The Kinect sensor provides analytic data that a clinician is unable to detect, such as speed of movement (average and maximum speed), acceleration (average and maximum acceleration) and patients’ movements within space. It also provides functional data such as the total points gained in the MIRA games Gaining points in the exergames requires balance, visual-spatial coordination, hand-eye coordination, attention, a satisfactory IQ and a good visual acuity. The MIRA platform provides adapted games for children with neurological impairments, with varying difficulty and exercises focusing on coordination. The Xbox Kinect does not require patients to hold a device during their exercises, which may be difficult for patients with neurological impairments to coordinate. The exergames are appreciated by both children and parents and can be considered a promising new tool for rehabilitation professionals in the treatment of children with cerebral palsy.

Keypoints

This paper presents the clinical evolution of a CP child after training with the exergames form the MIRA platform. It signals the emergence of a novel therapeutic instrument in the rehabilitation of the patients with CP. Since children like playing, the adapted movement-based interactive video games are an appealing method of rehabilitation for them, ensuring a good compliance to treatment.

References

Moldovan, IM, Călin, A, Cantea, A,  Dascălu A, Mihaiu, C, Ghircău, O, Onac, S, Rîză, O and Moldovan, RA, (2014), Development of a new scoring system for bilateral upper limb function and performance in children with cerebral palsy using the MIRA interactive video games and the Kinect sensor. Annals of 10th International Conference on Disability, Virtual Reality & Associated Technologies, 7, 44.

Zoccolillo, L, Morelli, D, Cincotti, F, Muzzioli, L, Gobbetti, T, Paolucci, S and Iosa, M, (2015), Video-game based therapy performed by children with cerebral palsy: a cross-over randomized controlled trial and a cross-sectional quantitative measure of physical activity. Eur J Phys Rehabil Med,  Feb 5, [Epub ahead of print].

Luna-Oliva, L, Ortiz-Gutiérrez, RM, Cano-de la Cuerda, R, Piédrola, RM, Alguacil-Diego, IM, Sánchez-Camarero, C, and Martínez Culebras, MC, (2013), Kinect Xbox 360 as a therapeutic modality for children with cerebral palsy in a school environment: a preliminary study, NeuroRehabilitation, 33, 4, pp. 513-521.



About the authors

ionut-moldovanDr Ionut Moldovan MD, PhD, neurorehabilitation physician, consultant at the Alba-Iulia Emergency County Hospital and at the ”Maria Beatrice” Socio-Medical Services Complex, Alba-Iulia, Romania. Dr. Moldovan is a member of the Romanian Society of Rehabilitation. His domain of interest consists in neurologic rehabilitation in children and adults, using both conventional therapies and innovative technologies, aiming to increase the quality of life and the functional independence in patients with neurological disabilities.






Appendix

1GMFCS

GMFCS Level I



Children walk at home, school, outdoors and in the community. They can climb stairs without the use of a railing. Children perform gross motor skills such as running and jumping, but speed, balance and coordination are limited.
GMFCS Level II



Children walk in most settings and climb stairs holding onto a railing. They may experience difficulty walking long distances and balancing on uneven terrain, inclines, in crowded areas or confined spaces.
Children may walk with physical assistance, a handheld mobility device or used wheeled mobility over long distances. Children have only minimal ability to perform gross motor skills such as running and jumping.
GMFCS Level III



Children walk using a hand-held mobility device in most indoor settings. They may climb stairs holding onto a railing with supervision or assistance. Children use wheeled mobility when traveling long distances and may self-propel for shorter distances.
GMFCS Level IV



Children use methods of mobility that require physical assistance or powered mobility in most settings. They may walk for short distances at home with physical assistance or use powered mobility or a body support walker when positioned. At school, outdoors and in the community children are transported in a manual wheelchair or use powered mobility.
GMFCS Level V



Children are transported in a manual wheelchair in all settings. Children are limited in their ability to maintain antigravity head and trunk postures and control leg and arm movements.

GMFCS descriptors copyright © Palisano et al. (1997) Dev Med Child Neurol 39:214-23 CanChild

Illustrations copyright Version 2 © Bill Reid, Kate Willoughby, Adrienne Harvey and Kerr Graham, The Royal Children’s Hospital Melbourne.

2MACS

MACS Level I Objects are handled easily and successfully
MACS Level II Handles objects with difficulty – the child will need help to prepare and/or modify activities.
MACS Level III Handles objects with difficulty – the child will need help to prepare and/or modify activities.
MACS Level IV Handles a limited selection of easily managed objects and always requires some help from others.
MACS Level V The child is not able to handle objects or to complete even simple actions with their hands.

Modified Ashworth Scale

Score Modified Ashworth Scale Bohannon & Smith (1987)
0 (0) No increase in muscle tone
1 (1) Slight increase in muscle tone, manifested by a catch and release or by minimal resistance at the end of the range of motion when the affected part(s) is moved in flexion or extension
1+ (2)



Slight increase in muscle tone, manifested by a catch, followed by minimal resistance throughout the reminder (less than half) of the ROM (range of movement)
2 (3) More marked increase in muscle tone through most of the ROM, but affected part(s) easily moved
3 (4) Considerable increase in muscle tone passive, movement difficult
4 (5) Affected part(s) rigid in flexion or extension

http://www.rehabmeasures.org/Lists/RehabMeasures/PrintView.aspx?ID=902
